A micro via is a small, plated hole in a PCB that allows for communication between different layers. Its small size and high conductivity make it an important component in many electronic products, especially those that require high-speed signal transmission. These conductive pathways, which are sometimes referred to as plated through-holes (PTH) or via holes, are used for routing a circuit’s signals to improve reliability and performance.

The maximum number of layers that a micro via can span depends on the fabrication technology used to create the board. One common method is known as HDI, or High Density Interconnection, which involves fabricating thin double-sided boards that are’sandwiched’ together. This enables blind and buried vias to connect between the layers of the boards.

In order to minimize signal losses, it’s necessary to optimize the layer-spanning capability of a micro via. This can be achieved by controlling the metallization process and using materials that are conducive to low loss and high impedance. Another important factor in microvia performance is the copper foil thickness, which can impact its conductivity and heat dissipation capabilities. In addition, the laser drilling process used to create the microvia has a significant influence on its quality. A laser that is used with precision can minimize issues, such as holes that are too large or inconsistently shaped.

Maximum Number of Layers in a Micro Via

It’s also possible to improve the performance of a microvia by using a staggered design. Staggered microvias are arranged so that they’re not stacked directly over each other, which can cause failure at the interface between them. In addition, by designing the underlying signal traces to be as short and tight as possible, it’s possible to reduce noise and improve signal timing, which can also improve reliability.

Micro vias are a fundamental component in modern electronics, playing a crucial role in enabling the miniaturization and densification of electronic devices. These tiny conduits serve as pathways for electrical signals to traverse through various layers of a printed circuit board (PCB) or semiconductor substrate. With the ever-increasing demand for smaller, lighter, and more powerful electronic devices, the importance of micro vias cannot be overstated.

When it comes to creating a microvia, an advanced padstack editor like Allegro PCB Designer can help. This tool gives designers the ability to specify the exact pad shapes and sizes for the various layers in a PCB, as well as control over drill sizes and tolerances. As a result, the tool makes it easy to create a via with the exact specifications needed for a particular project. This is especially helpful when it comes to avoiding problems caused by voiding, which can lead to stress concentrations and other problems. By working with a tool that offers these features, it’s easy to create a PCB with the right amount of layer-spanning capability and maximize its reliability.
